Ford Mondeo V (2014-2019) Cooling fan circuit, hybrid

ACTIVE GRILLE SHUTTER BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/GRN WIRE CABIN HEATER COOLANT PUMP CHT COMPUTER DATA LINES SYSTEM COOLING FAN MODULE CYLINDER HEAD TEMPERATURE (CHT) SENSOR ELECTRIC MOTOR COOLANT PUMP ENGINE COOLANT TEMPERATURE 2 SENSOR (ECT) ENGINE COOLING FAN RELAY FCV FUSE 12 FUSE 5 FUSE 60 FUSE 8 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HCHO HEATER CORE SHUTOFF HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED HS CAN+ LIN POWERTRAIN CONTROL MODULE (PCM) PWM RED WIRE SIGRTN VBATT VIO WIRE VIO/GRY WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE
