Ford Maverick III (2021-2024) pass frt crash sens rtn Wiring diagram
This page shows the only wiring diagram for the component.pass frt crash sens rtn, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass frt crash sens rtn (1 of 1)
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN/BLU WIRE
CANISTER VENT
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG (STEERING WHEEL)
DRIVER LOWER AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRT CRASH SENS FEED
DRV FRT CRASH SENS RTN
DRV KNEE AIR FEED
DRV KNEE AIR RTN
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CLUSTER (IPC) MODULE
LEFT FRONT IMPACT SEVERITY SENSOR
LEFT SIDE AIR BAG
LEFT SIDE CURTAIN AIR BAG
NCA WIRE
PAD INDICATOR OFF
PAD INDICATOR ON
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS AIR BAG CV FEED
PASS AIR BAG CV RTN
PASS FRT CRASH SENS FEED
PASS FRT CRASH SENS RTN
PASS LOAD LIMITED FEED
PASS LOAD LIMITED RTN
RCM PWR
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT IMPACT SEVERITY SENSOR
SHORTING BAR
STAGE 1
STAGE 2
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/O ACTIVE SEAT BELTS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> PASS FRT CRASH SENS RTN
