Ford Maverick III (2021-2024) mirror common fold out Wiring diagram
This page shows the only wiring diagram for the component.mirror common fold out, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror common fold out (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DEMAND LP/ BATT SAVE (FET)
DRIVER DOOR MODULE (DDM) (DRIVER DOOR)
DRIVER DOOR WINDOW CONTROL SWITCH
FUSE 14
FUSE 7
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT EXTERIOR MIRROR
MICRO -
MIRR LT/RT
MIRROR COMMON FOLD OUT
MIRROR LEFT
MIRROR UP
MS CAN +
NAVIGATION SYSTEM
PASSENGER DOOR MODULE (PDM) (PASSENGER DOOR)
RIGHT EXTERIOR MIRROR
VBATT
VIO/GRN WIRE
VIO/ORG WIRE
VPWR
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit, w/ door module -> MIRROR COMMON FOLD OUT
