Ford Maverick III (2021-2024) left interior front door handle ambient lighting lamp Wiring diagram
This page shows the only wiring diagram for the component.left interior front door handle ambient lighting lamp, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left interior front door handle ambient lighting lamp (1 of 1)
ALL WHEEL DRIVE (AWD) MODULE
BLK WIRE
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
GRN WIRE
GRY WIRE
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CONTROL SWITCH
LEFT INTERIOR FRONT DOOR HANDLE AMBIENT LIGHTING LAMP
LEFT REAR DOOR LATCH
LEFT REAR WINDOW CONTROL SWITCH
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PARKING AID MODULE (PAM)
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR WINDOW CONTROL SWITCH
PASSENGER DOOR)
RIGHT EXTERIOR MIRROR
RIGHT FRONT DOOR LATCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT REAR DOOR LATCH
RIGHT REAR WINDOW CONTROL SWITCH
RIGHT SEAT BELT BUCKLE SWITCH
RIGHT SEAT TRACK POSITION SENSOR
VIO WIRE
W/ AMBIENT LIGHTING
W/O DOOR MODULE
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> LEFT INTERIOR FRONT DOOR HANDLE AMBIENT LIGHTING LAMP
