Ford Maverick III (2021-2024) left front interior door handle ambient lighting lamp Wiring diagram
This page shows the only wiring diagram for the component.left front interior door handle ambient lighting lamp, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front interior door handle ambient lighting lamp (1 of 1)
AJAR
AJAR SW
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
DRV DOOR
GEAR SHIFT MODULE (GSM)
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/ORG WIRE
HIGH MOUNTED STOP LAMP
LEFT FOOTWELL LAMP
LEFT FRONT DOOR LATCH
LEFT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
LEFT TRUCK BED LAMP
LIN 08
LIN 11
MEDIA BIN AMBIENT LED
PWR
RIGHT FOOTWELL LAMP
RIGHT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
RIGHT TRUCK BED LAMP
YEL/BLU WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> LEFT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
