Ford Maverick III (2021-2024) hot w/ latching power point relay 2 energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ latching power point relay 2 energized, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ latching power point relay 2 energized (1 of 1)
AJAR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
FUSE 34
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
HEADLAMP SWITCH
HOT W/ LATCHING POWER POINT RELAY 2 ENERGIZED
LEFT REAR DOOR LATCH
LF DOOR AJAR
LR DOOR AJAR
MICRO -
REAR CARGO SW
RF DOOR AJAR
RIGHT FRONT DOOR LATCH
RIGHT REAR DOOR LATCH
RR DOOR AJAR
TRUCK BED LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> HOT W/ LATCHING POWER POINT RELAY 2 ENERGIZED
