Ford Maverick III (2021-2024) fuel sender signal Wiring diagram
This page shows the only wiring diagram for the component.fuel sender signal, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel sender signal (1 of 1)
2.0L TURBO
2.5L HYBRID
AAT
AMBIENT AIR TEMPERATURE (AAT) SENSOR
ANTI-LOCK BRAKES SYSTEM
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE (EOP) SWITCH
ENGINE OIL PRESSURE, TEMPERATURE (EOPT) SENSOR
EOP
FUEL LEVEL RETURN
FUEL PUMP, SENDER UNIT
FUEL SENDER SIGNAL
FUSE 22
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HILL DESCENT CONTROL
HOT AT ALL TIMES
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC) MODULE
IVD/TCS DISABLE
LF DOOR AJAR
LOW LEVEL WASHER FLUID
LR DOOR AJAR
MEGA FUSE
MICRO -
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
RF DOOR AJAR
RR DOOR AJAR
RTN
S112 (2.0L TURBO)
SIGRTN
TRANSMISSIONS SYSTEM
VBATT
VBATT 1 BUS
VREF
WHT WIRE
WHT/GRN WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> FUEL SENDER SIGNAL
