Ford Maverick III (2021-2024) exterior rear view mirror switch drv x Wiring diagram
This page shows the only wiring diagram for the component.exterior rear view mirror switch drv x, which is found in the car Ford Maverick III (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior rear view mirror switch drv x (1 of 1)
ACCESSORY DELAY RELAY
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/YEL WIRE
CIRCUIT BREAKER 1
DOWN
DR/DN
DR/UP
DRIVER DOOR WINDOW CONTROL SWITCH
DRIVER DOOR WINDOW REGULATOR MOTOR
EXTERIOR REAR VIEW MIRROR SWITCH DRV X
EXTERIOR REAR VIEW MIRROR SWITCH DRV Y
EXTERIOR REAR VIEW MIRROR SWITCH PASS X
EXTERIOR REAR VIEW MIRROR SWITCH PASS Y
EXTERIOR REAR VIEW MIRROR SWITCH RTN
GRN/ORG WIRE
GRN/YEL WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
ILLUM
LEFT REAR DOOR WINDOW REGULATOR MOTOR
LEFT REAR WINDOW CONTROL SWITCH
LOCK OUT
LOCK OUT BYPASS
LR DOWN
LR UP
MEGA FUSE
MICRO -
MIRRORS SYSTEM
RF DOWN
RF UP
RR DOWN
RR UP
VIO/GRY WIRE
VIO/WHT WIRE
VPWR
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power windows circuit, w/o door module (1 of 2) -> EXTERIOR REAR VIEW MIRROR SWITCH DRV X
