Ford Kuga III (2019-2024) Rear camera circuit

Rear camera circuit

Car Wiring Diagrams for Kuga Ford III (2019-2024): Rear camera circuit

BATTERY JUNCTION BOX (BJB) BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/VIO WIRE FUSE 25 HOT W/ RUN/START RELAY ENERGIZED LIN 06 MICRO - NCA WIRE REAR CAMERA VIDEO + REAR PARKING AID CAMERA SHIELD SYNC MODULE (APIM) VPWR WHT/GRN WIRE WHT/ORG WIRE YEL/VIO WIRE
