Warning systems circuit for Ford Kuga II (2012-2016)

AJAR BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRAKE/ BRK FLUID BRN/RED WIRE BRN/VIO WIRE CASE GND COMPUTER DATA LINES SYSTEM DRIVER SEAT BUCKLE SW FUSE 24 FUSE 78 FUSE 86 GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRY/ORG WIRE GRY/VIO WIRE HEADLAMP SWITCH HOT AT ALL TIMES HOT IN START OR RUN HS CAN+ IGN SW IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) INTERNAL ANTENNA RKE RECEIVER KEY IN KEY IN IGNITION LEFT FRONT SAFETY BELT TENSION SENSOR (BTS) LEFT FRONT SEAT TRACK POSITION SENSOR LF DOOR LIFTGATE LIFTGATE AJAR LIFTGATE/LUGGAGE COMPARTMENT LID LATCH LIN LOW BRAKE FLUID WARNING INDICATOR SWITCH LR DOOR LVL SW MICRO - MS CAN + MULTI- FUNCTION SWITCH NCA WIRE PARK PARKING BRAKE SWITCH PWR GND REAR GATE TRUNK MODULE (RGTM) RED WIRE RESTRAINTS CONTROL MODULE (RCM) RF DOOR RR DOOR RTN RUN/START STEERING COLUMN CONTROL MODULE (SCCM) SUPPLEMENTAL RESTRAINTS SYSTEM VBATT VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/ POWER LIFTGATE W/O INTELLIGENT ACCESS W/O POWER LIFTGATE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/ORG WIRE

AJAR BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) GRN WIRE GRN/VIO WIRE GRY/ORG WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES LEFT FRONT DOOR LATCH RELEASE MOTOR LEFT REAR DOOR LATCH RELEASE MOTOR LEFT REAR DOOR MODULE (DRDM) MEGA FUSE 4 MS CAN + PASSENGER DOOR MODULE (PDM) POWER WINDOWS SYSTEM RED WIRE RIGHT FRONT DOOR LATCH RELEASE MOTOR RIGHT REAR DOOR LATCH RELEASE MOTOR RIGHT REAR DOOR MODULE (PRDM) RTN VIO/ORG WIRE W/O DOOR MODULES W/ DOOR MODULES WHT WIRE YEL WIRE
