Power mirrors circuit, w/o door module for Ford Kuga II (2012-2016)
Power mirrors circuit, w/o door module
BATTERY JUNCTION BOX (BJB)
BLK/VIO WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DRIV L/R
DRIV U/D
DRIVER DOOR WINDOW CONTROL SWITCH
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 25
GRY WIRE
GRY/YEL WIRE
HOT W/ IGNITION RELAY ENERGIZED
LATE PRODUCTION EARLY PRODUCTION
LEFT EXTERIOR MIRROR
NCA WIRE
PASS L/R
PASS U/D
PWR
RETURN
RIGHT EXTERIOR MIRROR
WHT/ORG WIRE
YEL/VIO WIRE
