Ford Kuga II (2012-2016) (w/ door modules, memory) wiring diagram
This page shows the only wiring diagram for the component.(w/ door modules, memory), which is found in the car Ford Kuga II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(w/ door modules, memory) wiring diagram (1 of 1)
AUDIO UNIT
BLU/GRY WIRE
DRIVER DOOR MODULE (DDM)
DRIVER SEAT MODULE (DSM)
EARLY PRODUCTION
FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM)
FRONT CONTROLS INTERFACE MODULE (FCIM)
GRY WIRE
GRY/ORG WIRE
I CAN -
IMAGE PROCESSING MODULE (PM-B)
LATE PRODUCTION
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
MS CAN +
MSX CAN +
ORG/ WIRE
PASSENGER DOOR MODULE (PDM)
REAR GATE TRUNK MODULE (RGTM)
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
TRAILER MODULE
VIO/GRY WIRE
VIO/ORG WIRE
W/ DOOR MODULES
W/ POWER LIFTGATE
W/ SYNC GEN 1 (4.2 INCH DISPLAY)
W/ SYNC GEN 2 (8 INCH DISPLAY)
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (2 of 3) -> (W/ DOOR MODULES, MEMORY)
