Passive anti-theft circuit for Ford GT I (2004-2006)
Passive anti-theft circuit
1 2 3 4 VPWR GND TX RX
BLK WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENG COMPT)
COMPUTER DATA LINES SYSTEM
GRY/ORG WIRE
HOT IN START OR RUN
HS CAN + HS CAN - TX RX
LT GRN WIRE
LT GRN/YEL WIRE
NCA WIRE
PASSIVE ANTI-THEFT TRANSCEIVER (IN STEERING COLUMN)
PNK/LT GRN WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (RIGHT FRONT OF ENG COMPT)
RED WIRE
RED/YEL WIRE
SMART JUNCTION BOX (SJB) (RIGHT KICK PANEL) FUSE 19
STARTER RELAY
WHT/LT GRN WIRE
YEL WIRE
