Ford GT I (2004-2006) transmission shift sector wiring diagram
This page shows the only wiring diagram for the component.transmission shift sector, which is found in the car Ford GT I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
transmission shift sector wiring diagram (1 of 1)
4.0L
4.6L
A/C CLUTCH FIELD COIL
ANTI- THEFT HORN
ANTI-THEFT INHIBIT SWITCH
ANTI-THEFT LUGGAGE COMPARTMENT SWITCH
AUXILIARY RELAY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
COUPE
DEACTIVATOR SWITCH
DRIVER SAFETY BELT BUCKLE SWITCH
DRIVER SEAT POSITION SWITCH
DRIVER SIDE DOOR LOCK SWITCH
DRIVER SIDE FRONT SEAT ADJUST SWITCH
DUAL PRESSURE SWITCH
EXTERIOR REAR VIEW MIRROR VIEW SWITCH
FUEL PUMP DRIVER MODULE
HEATED POSITIVE CRANKCASE VENTILATION VALVE
HIGH MOUNTED STOP LAMP
LEFT FRONT DOOR AJAR
LEFT FRONT LUMBAR ADJUST SWITCH
LEFT FRONT MOTOR WINDOW
LEFT REAR PARK/STOP/ TURN LAMP 1
LEFT REAR PARK/STOP/ TURN LAMP 2
LEFT REAR POWER WINDOW MOTOR
LEFT REVERSING LAMP
LEFT TAIL LAMP
LICENSE PLATE LAMP LEFT REAR SIDE LAMP
LOW CURRENT BOARD
LUGGAGE COMPARTMENT
LUGGAGE COMPARTMENT LEFT OUTBOARD SUBWOOFER AMPLIFIER
LUGGAGE COMPARTMENT LID AJAR SWITCH
LUGGAGE COMPARTMENT LID RELEASE SOLENOID LUGGAGE COMPARTMENT LAMP
MASTER WINDOW ADJUST SWITCH
NCA WIRE
OCCUPANT CLASSIFICATION SENSOR MODULE PASSENGER SAFETY BELT BUCKLE SWITCH
ORG/ WIRE
PARKING BRAKE SWITCH
PASSENGER DOOR LOCK SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
PCM KEY- OFF RELAY
POWER POINT
REAR WINDOW ADJUST SWITCH
REAR WINDOW DEFROST GRID
RESTRAINTS CONTROL MODULE
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT POWER WINDOW MOTOR
RIGHT OUTBOARD SUBWOOFER AMPLIFIER
RIGHT REAR PARK/ STOP/TURN LAMP 2 RIGHT REAR PARK/ STOP/TURN LAMP 1
RIGHT REAR POWER WINDOW MOTOR CONVERTIBLE TOP AJAR SWITCH
RIGHT REVERSE LAMP RIGHT TALL LAMP
SHIELD
SMART JUNCTION BOX
TRANSMISSION SHIFT SECTOR
W/ SECURITY
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MOTOR OVERHEAD CONSOLE
Go to component -> Ground distribution circuit (2 of 2) -> TRANSMISSION SHIFT SECTOR
