Ford GT I (2004-2006) powertrain control module Wiring diagram
This page shows the only wiring diagram for the component.powertrain control module, which is found in the car Ford GT I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram powertrain control module (1 of 1)
4.0L
4.6L
A/C CLUTCH RELAY
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BRN/LT BLU WIRE
BRN/YEL WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENG COMPT)
CONVERTIBLE TOP LOWER RELAY
CONVERTIBLE TOP RAISE RELAY
DK GRN WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR UNLOCK RELAY
DRIVER SIDE FRONT SEAT ADJUSTER SWITCH
EXCEPT CONVERTIBLE
FOG LAMP RELAY
FROM
FRONT CIGAR LIGHTER
FUEL PUMP RELAY
FUSE (DIAGRAM 1 OF 4)
FUSE (DIAGRAM 2 OF 4)
FUSE 1 FUSE 61
FUSE 10
FUSE 11 FUSE 65
FUSE 12
FUSE 13
FUSE 14
FUSE 2
FUSE 3
FUSE 4
FUSE 41
FUSE 43
FUSE 45
FUSE 46
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 56
FUSE 57
FUSE 58
FUSE 6
FUSE 62
FUSE 7
FUSE 8
FUSE 9
FUSIBLE LINK A (8 GA-
GENERATOR
GRY WIRE
HIGH BEAM RELAY
HIGH SPEED ENGINE COOLING FAN RELAY
HORN RELAY
LEFT FRONT CHANNEL SUBWOOFER AMPLIFIER RIGHT FRONT CHANNEL SUBWOOFER AMPLIFIER
LEFT FRONT LUMBAR ADJUST SWITCH
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR
LOW SPEED ENGINE COOLING FAN RELAY
LT BLU WIRE
LT BLU/PNK WIRE
LT GRN/VIO WIRE
LUGGAGE COMPARTMENT LEFT OUTBOARD SUBWOOFER AMPLIFIER
LUGGAGE COMPARTMENT LID RELEASE RELAY
LUGGAGE COMPARTMENT RIGHT INBOARD SUBWOOFER AMPLIFIER
ORG/LT BLU WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE
RADIO
REAR WINDOW DEFROST RELAY
RED WIRE
RED/LT BLU WIRE
RED/ORG WIRE
RIGHT FRONT POWER WINDOW
RIGHT REAR POWER WINDOW MOTOR ABS CONTROL MODULE
SMART JUNCTION BOX (SJB) (AT RIGHT KICK PANEL)
STARTER MOTOR
STARTER RELAY
VIO/YEL WIRE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
WINDSHIELD WIPER MOTOR
YEL/GRN WIRE
Go to component -> Power distribution circuit (1 of 4) -> POWERTRAIN CONTROL MODULE
