Ford GT I (2004-2006) passive anti-theft transceiver clock spring Wiring diagram
This page shows the only wiring diagram for the component.passive anti-theft transceiver clock spring, which is found in the car Ford GT I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passive anti-theft transceiver clock spring (1 of 1)
4.6L: NEAR BUSS ELECTRICAL CENTER)
A/C COMPRESSOR CLUTCH DIODE
ABS CONTROL MODULE
ANTI-THEFT HOOD SWITCH
BATTERY
BLK WIRE
BLK/WHT WIRE
BLOW MOTOR RESISTER FRONT CIGAR LIGHTER
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENG COMPT)
CLIMATE CONTROL MODULE
CONVERTIBLE TOP LOWER RELAY
CONVERTIBLE TOP RAISE RELAY
DATA LINK CONNECTOR (DLC)
DOOR LOCK RELAY DRIVER DOOR UNLOCK RELAY
DOOR UNLOCK RELAY
ENGINE COOLING FAN MOTOR
FUEL PUMP RELAY
HAZARD FLASHER SWITCH MESSAGE CENTER SWITCH
HORN
INLET MANIFOLD RUNNER CONTROL (IMRC) MODULE
INSTRUMENT CLUSTER
LEFT FRONT CHANNEL SUBWOOFER AMPLIFIER
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
MAIN LIGHT SWITCH
MASS AIR FLOW (MAF SENSOR)
NCA WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER CLOCK SPRING
PCM POWER RELAY 1
PCM POWER RELAY 2
POWERTRAIN CONTROL MODULE (PCM)
RADIO
RIGHT FRONT CHANNEL SUBWOOFER AMPLIFIER
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
SHAKER RADIO
SHIELD
SMART JUNCTION BOX (SJB) (AT RIGHT KICK PANEL)
W/ 4.6L
W/ SECURITY
WHT WIRE
WIPER/ WASHER SWITCH
Go to component: -> Ground distribution circuit (1 of 2) -> PASSIVE ANTI-THEFT TRANSCEIVER CLOCK SPRING
