Ford GT I (2004-2006) park interlock solenoid Wiring diagram
This page shows the only wiring diagram for the component.park interlock solenoid, which is found in the car Ford GT I (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park interlock solenoid (1 of 1)
BLK WIRE
BUSSED ELECTRICAL CENTER(BEC) (RIGHT FRONT OF ENGINE COMPT)
FUSE 68
HOT AT ALL TIMES
IGNITION SWITCH
ILLUMINATION
KEY REMOVAL INHIBIT SOLENOID
LT BLU WIRE
LT GRN WIRE
O/D SWITCH
ORG/ WIRE
PARK INTERLOCK SOLENOID
RED/BLK WIRE
SMART JUNCTION LOW CURRENT BOARD BOX(SJB) (AT LEFT KICK PANEL)
TAN WIRE
TRANSMISSION SHIFT SELECTOR (IN CENTER CONSOLE)
TRANSMISSIONS SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Shift interlock circuit -> PARK INTERLOCK SOLENOID
