Ford GT I (2004-2006) ground distribution system Wiring diagrams
This page contains all the electrical diagrams for the component. ground distribution system, in which he is found in the car Ford GT I (2004-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ground distribution system (1 of 2)
ANTI-THEFT HOOD SWITCH (RIGHT FRONT OF ENGINE COMPT)
ANTI-THEFT HORN (RIGHT SIDE OF LUGGAGE COMPT)
ANTI-THEFT INHIBIT SWITCH (REAR OF DRIVER'S DOOR)
ANTI-THEFT LUGGAGE COMPARTMENT SWITCH (CENTER OF LUGGAGE COMPT LID)
ARM
BLK WIRE
BLK/LT GRN WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENG COMPT)
DIS- ARM
GROUND DISTRIBUTION SYSTEM
INTRUSION SENSE
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/PNK WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT LID AJAR SWITCH (CENTER OF LUGGAGE COMPT LID)
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE
PNK WIRE
RED WIRE
RED/LT BLU WIRE
TAN WIRE
VBATT
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/LT BLU WIRE
WHT/PNK WIRE
Go to component -> Door lock circuit (2 of 2) -> GROUND DISTRIBUTION SYSTEM
Wiring diagram ground distribution system (2 of 2)
ANTI-THEFT HOOD SWITCH (RIGHT FRONT OF ENGINE COMPT)
ANTI-THEFT HORN (RIGHT SIDE OF LUGGAGE COMPT)
ANTI-THEFT INHIBIT SWITCH (REAR OF DRIVER'S DOOR)
ANTI-THEFT LUGGAGE COMPARTMENT SWITCH (CENTER OF LUGGAGE COMPT LID)
ARM
BLK WIRE
BLK/LT GRN WIRE
BUSSED ELECTRICAL CENTER (BEC) (RIGHT FRONT OF ENG COMPT)
DIS- ARM
GROUND DISTRIBUTION SYSTEM
INTRUSION SENSE
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/PNK WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT LID AJAR SWITCH (CENTER OF LUGGAGE COMPT LID)
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE
PNK WIRE
RED WIRE
RED/LT BLU WIRE
TAN WIRE
VBATT
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/LT BLU WIRE
WHT/PNK WIRE
Go to component -> Forced entry circuit (2 of 2) -> GROUND DISTRIBUTION SYSTEM
