Ford Grand C-MAX II (2010-2015) pas sig 1 Wiring diagram
This page shows the only wiring diagram for the component.pas sig 1, which is found in the car Ford Grand C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pas sig 1 (1 of 1)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BST PWM
BST PWR
COMPUTER DATA LINES SYSTEM
EV HS CAN -
FUSE 19
FUSE 7
FUSE 8
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LF SENSOR HI
LF SENSOR LO
LR SENSOR HI
LR SENSOR LO
MP GND
MP SENSE
MP SIG
MS CAN +
NCA WIRE
PAS GND
PAS SIG 1
PAS SIG 2 23 24 PAS SENSEP
RED WIRE
RF SENSOR HI
RF SENSOR LO
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
RR SENSOR HI
RR SENSOR LO
VAC PUMP
VAC PUMP MON
VAC SEN GND
VAC SEN SIG
VAC SENS PWR
VACRC
VBATT
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> PAS SIG 1
