Ford Grand C-MAX II (2010-2015) parking brake warning indicator switch wiring diagram
This page shows the only wiring diagram for the component.parking brake warning indicator switch, which is found in the car Ford Grand C-MAX II (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
parking brake warning indicator switch wiring diagram (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE BOOSTER SOLENOID
BRAKE BOOSTER TRAVEL SENSOR
BRAKE BOOSTER VACUUM SENSOR
BRAKE PEDAL ASSEMBLY)
BRAKE PEDAL POSITION SWITCH
BRAKE VACUUM PUMP
BRK FLUID
BRN/VIO WIRE
BST PWM
BST PWR
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
FUSE 21
FUSE 22
FUSE 24
FUSE 72
FUSE 9
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HS CAN+
LEVEL SW
LOW BRAKE FLUID WARNING INDICATOR SWITCH
MICRO -
MS CAN +
PARKING BRAKE WARNING INDICATOR SWITCH
POWERTRAIN CONTROL MODULE (PCM)
PRK BRK SW
PWR GND
RED WIRE
RESTRAINTS CONTROL MODULE (RCM)
SASM SPLY
SIG RTN
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR MODULE (SASM)
STP LT SW
SYSTEM
VACUUM PUMP CUT-OFF RELAY
VACUUM PUMP RELAY
VBATT
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> PARKING BRAKE WARNING INDICATOR SWITCH
