Shift interlock circuit, hybrid for Ford Fusion I facelift (2005-2012)

59 43 HS CAN + HS CAN - 7 14 15 PARK DETECT HS CAN - HS CAN + BLK/VIO WIRE BLU/ORG WIRE BLU/RED WIRE BOO BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH) BSI (FET) COMPUTER DATA LINES SYSTEM FLOOR SHIFTER FUSE FUSE 2 FUSE 5 GRN WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES IGNITION SWITCH INHIBIT INSTRUMENT CLUSTER (IC) LOGIC MS MS CAN CAN PARK SWITCH POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT) SHIFT LOCK SOLENOID SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE YEL/RED WIRE
