Defoggers circuit, except hybrid for Ford Fusion I facelift (2005-2012)
Defoggers circuit, except hybrid
ANTENNA REAR DEF MODULE WINDOW PWR (RIGHT DEFROST REAR OF GRID TRUNK)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
DEFROST DEFROST REQUEST REQUEST
DEFROST RELAY
FUSE 38
FUSE 45
FUSE 6
FUSION, MILAN
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
HVAC HVAC MODULE MODULE (DATC) (EMTC) (CENTER (CENTER OF DASH) OF DASH)
LEFT SIDE RIGHT SIDE EXTERIOR EXTERIOR REAR REAR VIEW VIEW MIRROR MIRROR 6 7 6 7
MANUAL AUTOMATIC A/C A/C
ORG/ WIRE
RED WIRE
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
W/O MEMORY W/ MEMORY
WHT WIRE
YEL WIRE
