Car Wiring Diagrams for Passive anti-theft circuit for Ford Fusion I facelift (2005-2012)

BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EXCEPT HYBRID HYBRID FUSE GROUND GRY/ORG WIRE HOT AT ALL TIMES HOT IN START OR RUN HS CAN+ INSTRUMENT CLUSTER (IC) MOD GND MS CAN + PASSIVE ANTI-THEFT TRANSCEIVER MODULE (TOP OF STEERING COLUMN) PATS RX PATS TX POWER RED WIRE RUN/START RX OUTPUT SMART JUNCTION FUSE BOX (SJB) (LEFT SIDE OF DASH) TX INPUT VIO WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/ORG WIRE YEL/RED WIRE
