Ford Fusion I facelift (2005-2012) v cont neg Wiring diagram

BATTERY PACK SENSOR MODULE (BPSM) (BEHIND LEFT SIDE OF REAR SEAT) BLK/BLU WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE CS AOUT 1 CS AOUT 2 CS GND CS VREF GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/VIO WIRE INSTR CAN H INSTR CAN L LDL NCA WIRE ORG/BLK WIRE PACK HS CAN H PNK WIRE PNK/BLK WIRE PWR GND RED WIRE SIG RTN TSL 1 TSL 2 TSL 3 TSL 9 TSL RTN 1 TSL RTN 10 TSL RTN 2 TSL RTN 3 TSL RTN 9 V CONT NEG V CONT POS V PNEG V SD V TB NEG VIO WIRE WHT WIRE WHT/GRN WIRE YEL/BLK WIRE
