Ford Fusion I facelift (2005-2012) trs/oss vpwr Wiring diagram
This page shows the only wiring diagram for the component.trs/oss vpwr, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trs/oss vpwr (1 of 1)
AUTOMATIC TRANSMISSION
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENS
FLOOR SHIFTER
FPC
FPM
FPPWR
FPRTN
FUEL SENDER
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEATED OXYGEN
HS CAN+
HTR-12
HTR-13
IFS INPUT
INSTRUMENT CLUSTER (IC)
LCP VFS
NCA WIRE
OSS +
POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT)
RETURN
RLC
SIGNAL
SIGRTN
SOL PWR
SSE ON/OFF SOL
TCC VFS
TCS
TFT
TIP+
TR GND
TRANSMISSION CONTROL SWITCH
TRS
TRS/OSS VPWR
TSS
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component: -> Wiring diagram engine performance 3.0l (3 of 5) -> TRS/OSS VPWR
