Ford Fusion I facelift (2005-2012) prech ctlh Wiring diagram

BATTERY ENERGY CONTROL MODULE (BECM) (BEHIND LEFT SIDE OF REAR SEAT) BECM IN+ BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BLU/RED WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONT CRL NEGH CONT CRL NEGL CONT CRL POSH CONT CRL POSL DC/DC CONVERTER MODULE FVI- GRN WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE GRY/YEL WIRE HS CAN+ HV- HVDC+ HVI- INSTR CAN H INSTR CAN L NCA WIRE ORG/BLK WIRE ORG/WHT WIRE PACK HS CAN L PACK HS CANL PRECH CTLH PRECH CTLL PWR GND RED WIRE SIG RTN TEMP INLET TEMP INLET RTN VBATT VIO WIRE VIO/BRN WIRE VIO/WHT WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/VIO WIRE
