Ford Fusion I facelift (2005-2012) panel panel dimming wiring diagram
This page shows the only wiring diagram for the component.panel panel dimming, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
panel panel dimming wiring diagram (1 of 1)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
DEMAND LAMP/ BATTERY SAVER RELAY
DIMMER SWITCH
FRONT INTERIOR LAMP
FUSE
FUSE 10
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTING (FET)
LEFT VANITY MIRROR LAMP
LOGIC
LUGGAGE COMPARTMENT LAMP
LUGGAGE COMPARTMENT LID/ RELEASE SOLENOID/ AJAR SWITCH
ORG/ WIRE
PANEL DOME DIMMING DIM DEMAND GND UP DOWN
PANEL PANEL DIMMING
PUDDLE LAMP (FET)
REAR INTERIOR LAMP
RED WIRE
RIGHT VANITY MIRROR LAMP
SMART JUNCTION BOX (SJB)
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> PANEL PANEL DIMMING
