Ford Fusion I facelift (2005-2012) one touch integrated start diode wiring diagram
This page shows the only wiring diagram for the component.one touch integrated start diode, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
one touch integrated start diode wiring diagram (1 of 1)
6 SPEED TRANSMISSION
BATTERY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BATTERY JUNCTION STARTER RELAY BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/GRN WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/GRN WIRE
CHARGING CIRCUIT
CLUTCH CUT OFF SWITCH
COMPUTER DATA LINES SYSTEM
CPP-BT
EXCEPT 3.5L 3.5L
FUSE 27
FUSE 5
GRN/ORG WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HS CAN+
IGNITION SWITCH
LOCK
MODULE (PCM) (LEFT REAR OF ENGINE COMPT)
NCA WIRE
OFF
ONE TOUCH INTEGRATED START DIODE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL
RED WIRE
RUN WIRE
SDC
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SMC
SMR
STARTER MOTOR
STRT HS HS LOCK CAN CAN
TRANSMISSION
TRS
TRSW-PN
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Starting circuit -> ONE TOUCH INTEGRATED START DIODE
