Ford Fusion I facelift (2005-2012) logic luggage compartment release sw Wiring diagram

This page shows the only wiring diagram for the component.logic luggage compartment release sw, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram logic luggage compartment release sw (1 of 1)

Wiring diagram logic luggage compartment release sw for Ford Fusion I facelift (2005-2012)

Get access

BLK/GRY WIRE BLK/VIO WIRE BRN/BLU WIRE BRN/YEL WIRE FUSE 17 FUSE 5 GRY/ORG WIRE HOT AT ALL TIMES ILLUMINATION LOGIC LUGGAGE COMPARTMENT RELEASE SW LUGGAGE COMPARTMENT AJAR SW LUGGAGE COMPARTMENT LID RELEASE RELAY LUGGAGE COMPARTMENT LID RELEASE SWITCH MIDI FUSIBLE LINK RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO/GRY WIRE WHT WIRE WHT/BLU WIRE

Go to component: -> Trunk release circuit -> LOGIC LUGGAGE COMPARTMENT RELEASE SW
