Ford Fusion I facelift (2005-2012) left side exterior rear view mirror switch Wiring diagram

This page shows the only wiring diagram for the component.left side exterior rear view mirror switch, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left side exterior rear view mirror switch (1 of 1)

Wiring diagram left side exterior rear view mirror switch for Ford Fusion I facelift (2005-2012)

Get access

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE DEFOGGER SYSTEM GRN WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/VIO WIRE LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED LEFT SIDE EXTERIOR REAR VIEW MIRROR SWITCH MIRRORS SYSTEM NAVIGATION SYSTEM RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED RIGHT SIDE EXTERIOR REAR VIEW MIRROR SWITCH VIO WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component: -> Memory mirrors circuit (2 of 2) -> LEFT SIDE EXTERIOR REAR VIEW MIRROR SWITCH
