Ford Fusion I facelift (2005-2012) itcc sol + Wiring diagrams

This page contains all the electrical diagrams for the component. itcc sol +, in which he is found in the car Ford Fusion I facelift (2005-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram itcc sol + (1 of 2)

Wiring diagram itcc sol + for Ford Fusion I facelift (2005-2012)

Get access

ACTIVE TORQUE CONTROL COUPLING SOLENOID (VEHICLE UNDERBODY, NEAR FUEL TANK) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE COMPUTER DATA LINES SYSTEM FUSE GND ITCC SOL - GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN HS CAN + RUN/START B+ HS CAN+ ITCC SOL + MODULE (LEFT SIDE OF DASH) NCA WIRE RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> 3.0l, 4wd circuit -> ITCC SOL +

Wiring diagram itcc sol + (2 of 2)

Wiring diagram itcc sol + for Ford Fusion I facelift (2005-2012)

Get access

ACTIVE TORQUE CONTROL COUPLING SOLENOID (VEHICLE UNDERBODY, NEAR FUEL TANK) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE COMPUTER DATA LINES SYSTEM FUSE GND ITCC SOL - GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN HS CAN + RUN/START B+ HS CAN+ ITCC SOL + MODULE (LEFT SIDE OF DASH) NCA WIRE RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

Go to component: -> 3.5l, 4wd circuit -> ITCC SOL +
