Ford Fusion I facelift (2005-2012) fuse 40 fuse 47 Wiring diagram
This page shows the only wiring diagram for the component.fuse 40 fuse 47, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 40 fuse 47 (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH)
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIODE
ENS
FPC
FPM
FPPWR
FPRTN
FUEL PUMP
FUEL SENDER
FUEL SENDER SIGNAL
FUEL TANK UNIT (TOP OF FUEL TANK)
FUSE 23
FUSE 3 FUSE 39
FUSE 40 FUSE 47
FUSE 45 FUSE 30
FUSE 46
FUSE 48
FUSE 49
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IFS VPWR
INJECTOR RELAY
INSTRUMENT CLUSTER (IC)
JUNCTION BOX
M/E COOLANT HEATER PUMP PUMP RELAY RELAY
MS CAN +
NCA WIRE
RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE)
RETURN
REVERSE LAMP RELAY
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.5l, hybrid (2 of 8) -> FUSE 40 FUSE 47
