Ford Fusion I facelift (2005-2012) except milan Wiring diagram

This page shows the only wiring diagram for the component.except milan, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram except milan (1 of 1)

Wiring diagram except milan for Ford Fusion I facelift (2005-2012)

Get access

BALLAST BATTERY JUNCTION BOX (BJB) BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE EXCEPT MILAN FUSE 26 FUSE 27 GRN WIRE GRY WIRE HI BEAM HID LOW BEAM LEFT HEADLAMP HID LOW BEAM RIGHT HEADLAMP HOT AT ALL TIMES LEFT HIGH INTENSITY DISCHARGE HEADLAMP RELAY MILAN MODULE RED WIRE RIGHT HIGH INTENSITY DISCHARGE HEADLAMP RELAY SHUTTER SOLENOID VIO WIRE YEL WIRE YEL/VIO WIRE

Go to component: -> Headlights circuit, except hybrid with hid headlights (1 of 2) -> EXCEPT MILAN
