Ford Fusion I facelift (2005-2012) defrost req batt blower cmd recirc cw recirc ccw Wiring diagrams

This page contains all the electrical diagrams for the component. defrost req batt blower cmd recirc cw recirc ccw, in which he is found in the car Ford Fusion I facelift (2005-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram defrost req batt blower cmd recirc cw recirc ccw (1 of 2)

Wiring diagram defrost req batt blower cmd recirc cw recirc ccw for Ford Fusion I facelift (2005-2012)

Get access

24 25 26 BLOWER RQST MS CAN+ MS CAN- AMP BATTERY JUNCTION BLK/GRY WIRE BLK/VIO WIRE BLOWER MOTOR (RIGHT SIDE OF HVAC HOUSING) BLOWER MOTOR RELAY BLOWER MOTOR SPEED CONTROL (RIGHT SIDE OF HVAC HOUSING) BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BRN/GRN WIRE BRN/WHT WIRE CMD COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DEFROST REQ BATT BLOWER CMD RECIRC CW RECIRC CCW FUSE 15 FUSE 35 FUSE 45 LOGIC GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) HOT IN RUN OR ACC HVAC-DATC (CENTER OF DASH) IN CAR TEMP SENS IN-VEHICLE TEMPERATURE SENSOR (LEFT SIDE OF DASH) MODE DR 1 CCW MODE DR 1 CW DRV TEMP DR CCW DRV TEMP DR CW GND MOT- PASS TEMP DR CCW PASS TEMP DR CW PASS TEMP DR FDBK PASSENGER TEMPERATURE BLEND DOOR ACTUATOR (CENTER OF HVAC HOUSING) SEATS SYSTEM VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR VREF RET WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Automatic a/c circuit, except hybrid (1 of 3) -> DEFROST REQ BATT BLOWER CMD RECIRC CW RECIRC CCW

Wiring diagram defrost req batt blower cmd recirc cw recirc ccw (2 of 2)

Wiring diagram defrost req batt blower cmd recirc cw recirc ccw for Ford Fusion I facelift (2005-2012)

Get access

24 25 26 BLOWER RQST MS CAN+ MS CAN- AMP BATTERY JUNCTION BLK/GRY WIRE BLK/VIO WIRE BLOWER MOTOR (RIGHT SIDE OF HVAC HOUSING) BLOWER MOTOR RELAY BLOWER MOTOR SPEED CONTROL (RIGHT SIDE OF HVAC HOUSING) BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BRN/GRN WIRE BRN/WHT WIRE CMD COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DEFROST REQ BATT BLOWER CMD RECIRC CW RECIRC CCW FUSE 15 FUSE 35 FUSE 37 FUSE 45 LOGIC GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) HOT IN RUN OR ACC HOT IN RUN OR START HUMIDITY SENS IN CAR TEMP SENS HVAC-DATC (CENTER OF DASH) IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR (LEFT SIDE OF DASH) MODE DR 1 CCW MODE DR 1 CW DRV TEMP DR CCW DRV TEMP DR CW GND MOT- PASS TEMP DR CCW PASS TEMP DR CW PASS TEMP DR FDBK PASSENGER TEMPERATURE BLEND DOOR ACTUATOR (CENTER OF HVAC HOUSING) SEATS SYSTEM VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR VREF RET WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Automatic a/c circuit, hybrid (1 of 3) -> DEFROST REQ BATT BLOWER CMD RECIRC CW RECIRC CCW
