Ford Fusion I facelift (2005-2012) cid 2 cid 1 ckp sensor - ckp sensor + Wiring diagram

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE CID 2 CID 1 CKP SENSOR - CKP SENSOR + E SIGRTN ETCRTN GEN COM GEN MON GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEATED OXYGEN SENSOR HTR 12 HTR 22 POWER STEERING PRESSURE SWITCH (RIGHT REAR OF ENGINE COMPT) POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT) PSPT PSPT ETCREF VCT VCT 2 HTR 11 HTR 21 SHDRTN CHT STARTING/CHARGING SYSTEM TACM - INJ 1 INJ 3 INJ 5 VARIABLE CAMSHAFT TIMING (VCT) SOLENOID VALVE 1 (TOP FRONT OF RIGHT VALVE COVER) VARIABLE CAMSHAFT TIMING (VCT) SOLENOID VALVE 2 (TOP FRONT OF LEFT VALVE COVER) VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VRSRTN TACM + INJ 2 INJ 4 INJ 6 WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
