Ford Fusion I facelift (2005-2012) (body main harness, near breakout to Wiring diagram
This page shows the only wiring diagram for the component.(body main harness, near breakout to, which is found in the car Ford Fusion I facelift (2005-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (body main harness, near breakout to (1 of 1)
ACCESSORY DELAY RELAY
AMBIENT LIGHTING MODULE
AMBIENT SELECT SWITCH
AUTO DIMMING INTERIOR MIRROR
BACKLIGHTING (FET)
BLU WIRE
CIRCUIT BREAKER 47
DEMAND LAMP/ BATTERY SAVER RELAY
FROM FRONT CIGAR LIGHTER (DIAGRAM 2 OF 5)
FROM FUSE 21 (DIAGRAM FUSE 22 4 OF 5)
FUSE 10
FUSE 25
FUSE 41
FUSE 5
FUSE 6
FUSE 9
FUSION, MILAN
GRN WIRE
INTERIOR LIGHTING BSI (FET) (FET)
KEYPAD LOGIC ILLUM (FET)
LEFT FRONT TURN LAMP (FET)
LEFT REAR PARK/TURN LAMP (FET)
LEFT REAR TURN LAMP (FET)
MASTER WINDOW CONTROL SWITCH
MASTER WINDOW DRIVER SIDE CONTROL DOOR LOCK SWITCH SWITCH (W/ SMART WINDOW)
MULTIMEDIA REAR VIEW CAMERA INTERIOR MIRROR DISPLAY UNIT MIRROR
OVERHEAD LIGHTING (EARLY PRODUCTION W/ MKZ AMBIENT LIGHTING)
PARK LAMP RELAY
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH (W/ SMART WINDOW)
PUDDLE LAMP (FET)
RIGHT FRONT TURN LAMP (FET)
RIGHT REAR PARK/TURN LAMP (FET)
RIGHT REAR TURN LAMP (FET)
ROOF OPENING PANEL MODULE
ROOF OPENING PANEL SWITCH
TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
W/O SMART WINDOW W/ SMART WINDOW
Go to component: -> Power distribution circuit, except hybrid (5 of 5) -> (BODY MAIN HARNESS, NEAR BREAKOUT TO
