Ford Fusion I facelift (2005-2012) anti-theft system power distribution system Wiring diagram

ANTI-THEFT SYSTEM POWER DISTRIBUTION SYSTEM BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BRN/RED WIRE BRN/YEL WIRE DIMMING CTRL FRONT FOG LAMP RLY GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM IGN RUN OR ACC SW IGN RUN OR START SW IGNITION SWITCH INSTRUMENT CLUSTER SYSTEM HEADLIGHTS SYSTEM POWER DISTRIBUTION SYSTEM INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM KEY IN LCK OFF POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM INSTRUMENT CLUSTER SYSTEM POWER DISTRIBUTION SYSTEM SOUND SYSTEMS RUN WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SOUND SYSTEMS STARTER DIODE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
