Ford Fusion I facelift (2005-2012) 19 14 15 18 +b hs can- hs can+ traction ctrl on/off Wiring diagram

19 14 15 18 +B HS CAN- HS CAN+ TRACTION CTRL ON/OFF 20 19 9 10 TC CAN STAT+ TC CAN STAT- HS CAN - HS CAN + ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (RIGHT REAR OF ENGINE COMPT) BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE BOOSTER SOLENOID (LEFT REAR OF ENGINE COMPT) BRAKE BOOSTER TRAVEL SENSOR BRAKE BOOSTER VACUUM SENSOR (ON BRAKE BOOSTER) BRAKE PEDAL ANGLE SENSOR (ON BRAKE PEDAL ASSEMBLY) BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONSOLE) CUT-OFF VALVE PRESSURE SENSOR FUSE 37 FUSE 47 FUSE FUSE 7 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES BATTERY JUNCTION FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES SMART JUNCTION FUSE BOX (SJB) (LEFT SIDE OF DASH) HOT IN RUN OR START INSTRUMENT PANEL (IC) LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (LEFT REAR HUB ASSEMBLY) NCA WIRE PS GND RED WIRE RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR HUB ASSEMBLY) RUN/START SIMULATOR CUT-OFF VALVE SOLENOID TRACTION CONTROL/ AMBIENT LIGHTING SWITCH VAC SIG 2 PM SENSE MP GND VAC VACUUM PUMP CUT-OFF RELAY VACUUM PUMP MOTOR (LEFT SIDE OF ENGINE) VACUUM PUMP RELAY VIO WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
