Car Wiring Diagrams for Charging circuit for Ford Freestyle I (2004-2009)

ALT COM ALT MON BATTERY BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) FUSE 17 BLK WIRE BLK/ORG WIRE FUSIBLE LINK A (12 GA, GRAY) FUSIBLE LINK B (12 GA, GRAY) GENERATOR RC AS GRY WIRE HOT IN START OR RUN HS CAN+ IG B+ INSTRUMENT CLUSTER RUN/START POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) RED WIRE RED/YEL WIRE SMART FUSE 20 JUNCTION BOX (SJB) (LEFT SIDE OF DASH) STARTER MOTOR WHT WIRE WHT/BLK WIRE YEL WIRE YEL/LT BLU WIRE
