Driver power seat circuit, with recliner for Ford Freestyle I (2004-2009)
Driver power seat circuit, with recliner
BASE
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
DK GRN WIRE
DN UP
DRIVER SEAT FRONT HEIGHT MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR HEIGHT MOTOR
DRIVER SEAT RECLINER MOTOR
DRIVER SIDE FRONT SEAT ADJUST SWITCH
FRONT
FUSE
FWD RWD
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
REAR
RECLINER
RED WIRE
RWD FWD
WHT WIRE
YEL WIRE
