Headlights circuit, with autolamps for Ford Freestyle I (2004-2009)

1 LO HI 1 LO RIGHT HEADLAMP HI AIR CONDITIONING SYSTEM AUTOLAMP BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/ORG WIRE FOG LAMP ILLUMINATION FOG LAMP RELAY FTP FTP LOW FUSE 1 FUSE 18 FUSE 23 GRN WIRE HEAD AUTOLAMP ON HEADLAMP SWITCH HIGH BEAM RELAY HOT AT ALL TIMES HSD ILLUMINATION INSTRUMENT CLUSTER LAMPS FOG LEFT FRONT FOG LAMP LEFT HEADLAMP LOGIC LT BEAM LT BLU WIRE LT DK DK LT LT LT LT DK LT LT LT LT GRN WIRE LT GRN/BLK WIRE MS CAN + MULTI- FUNCTION SWITCH (IN STEERING COLUMN) OFF OFF PARK ORG/ WIRE RED WIRE RIGHT FRONT FOG LAMP RT BEAM SENSE SENSE SENSE SENSE SENSE SENSE SENSE HSD SENSE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SOLID STATE CONTROL SUNLOAD AUTOLAMP/ SUNLOAD SENSOR (TOP CENTER OF DASH) TAN WIRE VBATT VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/WHT WIRE
