Exterior lamps circuit for Ford Freestyle I (2004-2009)

ACTUATOR AUTO LAMP BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/YEL WIRE BRAKE PEDAL STATUS BRN/WHT WIRE CHMSL LAMP SW SIG COMPUTER DATA LINES SYSTEM CONTROL DK BLU/ORG WIRE DK BLU/WHT WIRE FTP FTP LOW LOW HI HI FUSE 8 GRY/BLK WIRE GRY/LT BLU WIRE HAZARD FLASHER SW SIG HEAD PARK OFF HEADLAMP OFF SIG AUTO LAMP ON SIG PARKING BRAKE SW SIG HEADLAMP SWITCH HI BEAM SIG FLASH TO PASS RIGHT TURN HOT AT ALL TIMES HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT) FUSE 18 INSTRUMENT CLUSTER LEFT LEFT FRONT CONTROL TURN LAMP LEFT FRONT PARK/ TURN LAMP LEFT FRONT SIDE LAMP LEFT REAR TURN/ STOP/ HAZARD LAMPS SIG RIGHT REAR TURN/ STOP/ HAZARD LAMPS SIG LEFT TURN LO BEAM SIG PARK LAMP SIG LOGIC LT BLU/RED WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/RED WIRE MS CAN + MULTI- FUNCTION SWITCH (IN STEERING COLUMN) ORG/BLK WIRE PARK PARK LAMP RELAY RED WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RIGHT FRONT CONTROL TURN LAMP RIGHT FRONT PARK/ TURN LAMP RIGHT FRONT SIDE LAMP SIG SW ILLUM TAN/LT BLU WIRE TAN/WHT WIRE TURN VBATT WHT/BLK WIRE WHT/RED WIRE

ABS CONTROL MODULE (LEFT REAR OF ENGINE COMPT) BACKUP LAMPS CIRCUIT BLK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH) BRN/WHT WIRE CENTER STACK SWITCH ASSEMBLY DK GRN/VIO WIRE FLOOR SHIFTER FUSE 18 GRY/LT BLU WIRE HAZARD HIGH MOUNTED STOPLAMP HOT IN RUN OR START ILLUM INSTRUMENT CLUSTER SYSTEM LEFT REAR LAMP ASSEMBLY LICENSE LAMPS LT GRN/RED WIRE NAVIGATION SYSTEM NCA WIRE PARK LAMP PARKING AID ENABLE PARKING BRAKE SWITCH (LEFT SIDE OF DASH) RED/LT GRN WIRE RED/YEL WIRE REVERSING LAMP RIGHT REAR LAMP ASSEMBLY RPA IND SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) STOP/ TURN LAMP TAN/LT BLU WIRE TCS ENABLE TCS IND VIO WIRE VIO/ORG WIRE WHT/PNK WIRE WHT/RED WIRE WHT/YEL WIRE
