Defoggers circuit for Ford Freestyle I (2004-2009)
Defoggers circuit
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF OF ENGINE COMPARTMENT)
BLK WIRE
BRN WIRE
DK GRN WIRE
DK GRN/VIO WIRE
FIVE HUNDRED, MONTEGO
FREESTYLE
FUSE 16
FUSE 17
FUSE 20
GRY WIRE
HEATED BACKLIGHT RELAY
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR 15 6
LT BLU WIRE
NCA WIRE
PNK WIRE
REAR WINDOW DEFROST GRID
RIGHT EXTERIOR REAR VIEW MIRROR 15 6
SJB LOGIC
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TAN WIRE
VIO WIRE
W/ EATC W/O EATC 3 4
W/ MEMORY W/O MEMORY
