Ford Freestyle I (2004-2009) parking aid module Wiring diagram
This page shows the only wiring diagram for the component.parking aid module, which is found in the car Ford Freestyle I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking aid module (1 of 1)
AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY
BLK WIRE
DIFFERENTIAL ELECTRONIC MODULE (DEM)
FUEL PUMP DRIVER MODULE
HEATED SEAT MODULE
LEFT REAR DOOR AJAR SWITCH
LEFT REAR LAMP ASSEMBLY
NCA WIRE
ORG/ WIRE
PARKING AID MODULE
PASSENGER SAFETY BELT BUCKLE SWITCH
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE FRONT SEAT ADJUST SWITCH
REAR SEAT ENTERTAINMENT MODULE
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT SEAT BACK HEATER
RIGHT REAR DOOR AJAR SWITCH
RIGHT REAR LAMP ASSEMBLY
SATELITE RADIO RECEIVER
SHIELD
SUBWOOFER AMPLIFIER
W/O MEMORY W/ MEMORY
Go to component -> Ground distribution circuit (4 of 4) -> PARKING AID MODULE
