Supplemental restraints circuit, electric for Ford Focus III (2011-2015)

AMBER BLK WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE CASE GROUND CLOCK SPRING (TOP OF STEERING COLUMN) COLLAPSIBLE STEERING COLUMN MODULE (TOP LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DRIVER AIR BAG MODULE (IN STEERING WHEEL) DRIVER LOWER AIR BAG MODULE (UNDER LEFT SIDE OF DASH) DRIVER SAFETY BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) DRIVER SIDE FRONT DOOR IMPACT SENSOR (FRONT OF DRIVER DOOR) DRV FRT CR SN FEED PASS FRT CR SN FEED PASS FRT CR SN RTN PAD IND DRV SEAT BUCKLE SWITCH ENS ENS RUN/START FUSE 86 MICRO GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE HOT W/ IGN RELAY ENERGIZED HS CAN + HS CAN - INPUT LEFT FRONT SEAT TRACK POSITION SENSOR (OUTSIDE SEAT TRACK OF LEFT SEAT) LEFT SIDE SECOND ROW IMPACT SENSOR (BASE OF LEFT "C" PILLAR) NCA WIRE PAD IND PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH PASSENGER SIDE FRONT DOOR IMPACT SENSOR (FRONT OF PASSENGER DOOR) RESTRAINTS CONTROL MODULE (RCM) (UNDER FRONT OF CENTER CONSOLE) RIGHT FRONT SEAT TRACK POSITION SENSOR (OUTSIDE SEAT TRACK OF RIGHT SEAT) RIGHT SIDE SECOND ROW IMPACT SENSOR (BASE OF RIGHT "C" PILLAR) RTN STAGE 1 STAGE 2 VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

1 2 3 4 5 6 RUN/START HS CAN + HS CAN - GND BTS_VREF BTF_SIG 13 12 MS CAN- MS CAN+ BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SAFETY BELT ANCHOR PRETENSIONER (BASE OF DRIVER "B" PILLAR) ENS GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT IMPACT SEVERITY SENSOR (LEFT FRONT CORNER OF MOTOR COMPT) LEFT SIDE AIR CURTAIN MODULE (TOP OF LEFT "C" PILLAR) NCA WIRE PASSENGER AIR BAG MODULE PASSENGER SAFETY BELT ANCHOR PRETENSIONER (BASE OF PASSENGER "B" PILLAR) PASSENGER SAFETY BELT BUCKLE PASSENGER SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF RIGHT "B" PILLAR) PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF RIGHT "B" PILLAR) RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT CORNER OF MOTOR COMPT) RIGHT FRONT SIDE AIR BAG MODULE RIGHT SIDE AIR CURTAIN MODULE (TOP OF RIGHT "C" PILLAR) SHORTING BAR STAGE 1 STAGE 2 UPPER HIGH VOLTAGE BATTERY PACK (BEHIND REAR SEATS) VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
