Power windows circuit, except electric without door module & rear power window for Ford Focus III (2011-2015)
Power windows circuit, except electric without door module & rear power window
4 1 7 UP DN
BATTERY
BLK WIRE
BLK/VIO WIRE
BRN/GRN WIRE
BRN/YEL WIRE
DN RIGHT FRONT SWITCH
DRIVER SIDE FRONT POWER WINDOW (BELOW FRONT DRIVER MOTOR SCUFF PLATE)
FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRY/ORG WIRE
HOT W/ IGNITION RELAY ENERGIZED
LEFT FRONT SWITCH
MASTER WINDOW CONTROL SWITCH
MIRROR SWITCHES PWR
MIRRORS SYSTEM
PASSENGER SIDE FRONT POWER WINDOW MOTOR
PASSENGER SIDE WINDOW CONTROL SWITCH
PWR PASS L/R RETURN PASS U/D DRIV L/R RETURN DRIV U/D
RIGHT FRONT SWITCH
VIO/GRN WIRE
WHT/VIO WIRE
