Heated seats circuit, electric for Ford Focus III (2011-2015)
Heated seats circuit, electric
BLK WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM) (LOWER RIGHT SIDE OF DASH)
BRN WIRE
DRIVER SIDE FRONT HEATED SEAT MODULE (UNDER FRONT OF DRIVER SEAT)
DRIVER SIDE HEATER SEAT SWITCH
DRV HEATER FEED
DRV ST NTC SENSE
FUSE 34
FUSE 35
FUSE 85
GRY WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY ENERGIZED
LEFT FRONT SEAT BACKREST HEATER
LEFT FRONT SEAT CUSHION HEATER
PASS HEATER FEED
PASS ST NTC SENSE
PASSENGER SIDE FRONT HEATED SEAT MODULE (UNDER FRONT OF PASSENGER SEAT)
PASSENGER SIDE HEATER SEAT SWITCH
REAR JUNCTION BOX (BJB) (LEFT REAR CORNER OF VEHICLE)
RIGHT FRONT SEAT BACKREST HEATER
RIGHT FRONT SEAT CUSHION HEATER
VIO WIRE
VPWR
YEL WIRE
YEL/BLK WIRE
