Horn circuit, electric for Ford Focus III (2011-2015)
Horn circuit, electric
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH)
BRN WIRE
CLOCKSPRING (TOP OF STEERING COLUMN)
FUSE 20
FUSE 23
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HIGH CURRENT BATTERY MEGA FUSE 9 JUNCTION BOX (BJB) (LEFT SIDE OF MOTOR COMPT)
HORN
HORN (RIGHT FRONT OF MOTOR COMPT)
HORN RC
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
LOGIC GND
MEGA FUSE 4
MICRO -
ORG/ WIRE
RED WIRE
VBATT
VIO WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
