Electronic power steering circuit, except electric for Ford Focus III (2011-2015)
Electronic power steering circuit, except electric
1 2 3 HS CAN + HS CAN - VPWR
1 2 VBATT PWR GND
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
MEGA 1 FUSE
MOTOR
POWER STEERING CONTROL MODULE (PSCM)
WHT WIRE
WHT/BLU WIRE
