Cooling fan circuit, electric for Ford Focus III (2011-2015)
Cooling fan circuit, electric
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF MOTOR COMPT)
BLK/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONICS ENGINE COOLING FAN MOTOR (LEFT FRONT OF MOTOR COMPT)
ENGINE COOLING FAN RELAY
EV HS CAN -
FAN CONTROL VARIABLE
FCV
FUSE 32
GRN/RED WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (LEFT SIDE OF MOTOR COMPT)
HOT AT ALL TIMES
HOT IN ON OR START
MEGA FUSE 8
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (FRONT OF LEFT FRONT WHEELWELL)
PWR
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
